LEGACY SERIES

The Legacy Series consists of PILOT’s Iconic range of Spray Guns which typically operate at higher air pressures and are used for coating any type of surface/object. High air pressure results in super fine atomization resulting in a smoother & high quality spray finish

LEGACY

SERIES

Standard or Conventional spray guns typically operate at higher air pressure and are used for coating any type of surface/object. High air pressure results in super fine atomization resulting in a smoother spray finish.

TYPE 59 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Balanced handle for comfortable & firm grip
  • Built-in spreader control for round & fan flow patterns
TECHNICAL DATA
Code No. 59000N
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.8-4.2
Air consumption of rated pressure lit/min (c.f.m) 225-300 (8-10)
Material output (cc/min) 325
Max. pattern width (mm) 250
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 660
pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture

Pharmaceuticals - Pilot IndiaPharmaceuticals



TYPE 59 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Balanced handle for comfortable & firm grip
  • Built-in spreader control for round & fan flow patterns
AREAS OF APPLICATION
Industrial - Pilot India
Industries
- Pilot India
Textile
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Pharmaceuticals - Pilot India
Pharmaceuticals
Type 59N - Pilot India
TECHNICAL DATA
Code No. 59000N
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.8-4.2
Air consumption of rated pressure lit/min (c.f.m) 225-300 (8-10)
Material output (cc/min) 325
Max. pattern width (mm) 250
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 660

pdf 1 - Pilot India   Download product cataloguepdf 1 - Pilot India   Download product manual

TYPE 59 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Balanced handle for comfortable & firm grip
  • Symmetric & durable gravity cup
  • Built-in spreader control for round & fan flow patterns
TECHNICAL DATA
Code No. 59000S
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.8-4.2
Air consumption of rated pressure lit/min (c.f.m) 225-300 (8-10)
Material output (cc/min) 325
Max. pattern width (mm) 250
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 747
pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

AREAS OF APPLICATION

Industrial - Pilot India
Industries
Automobiles - Pilot India
Automobiles
- Pilot India
Textile
Furniture - Pilot India
Furniture
Pharmaceuticals - Pilot IndiaPharmaceuticals

TYPE 59 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Balanced handle for comfortable & firm grip
  • Symmetric & durable gravity cup
  • Built-in spreader control for round & fan flow patterns

AREAS OF APPLICATION

Industrial - Pilot India
Industries
- Pilot India
Textile
Pharmaceuticals - Pilot IndiaPharmaceuticals
Furniture - Pilot India
Furniture
Automobiles - Pilot India
Automobiles
Type 59S - Pilot India
TECHNICAL DATA
Code No. 59000S
Cup capacity (litres)- 0.57
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.8-4.2
Air consumption of rated pressure lit/min (c.f.m) 225-300 (8-10)
Material output (cc/min) 325
Max. pattern width (mm) 250
Min. Air-compressor (HP) 1-2
Weight of gun with cup (gms) 747

pdf 1 - Pilot India   Download product catalogue
pdf 1 - Pilot India   Download product manual

TYPE 64 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern
TECHNICAL DATA
Code No. 64000N
Cup capacity (litres)- 0.34
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.1-2.8
Air consumption of rated pressure lit/min (c.f.m) 115 – 170 (4-6)
Material output (cc/min) 300
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 357
pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

AREAS OF APPLICATION

Electrical equipment - Pilot India
Electrical
Automobiles - Pilot India
Automobiles
Handicrafts - Pilot India
Handicrafts
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports Goods

TYPE 64 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern

AREAS OF APPLICATION

Electrical equipment - Pilot India
Electrical
Handicrafts - Pilot India
Handicraft
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
Type 64 N - Pilot India
TECHNICAL DATA
Code No. 64000N
Cup capacity (litres)- 0.34
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.1-2.8
Air consumption of rated pressure lit/min (c.f.m) 115 – 170 (4-6)
Material output (cc/min) 300
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 357

pdf 1 - Pilot India   Download product catalogue

pdf 1 - Pilot India   Download product manual

TYPE 64 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern
TECHNICAL DATA
Code No. 64000S
Cup capacity (litres)- 0.34
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.1-2.8
Air consumption of rated pressure lit/min (c.f.m) 115 – 170 (4-6)
Material output (cc/min) 300
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 457
pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

AREAS OF APPLICATION

Electrical equipment - Pilot India
Electrical
Automobiles - Pilot India
Automobiles
Handicrafts - Pilot India
Handicrafts
Furniture - Pilot India
Furniture
Sports - Pilot IndiaSports Goods

TYPE 64 S

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Symmetric & durable gravity cup
  • Lightweight & less operator fatigue
  • Rotatable air cap facilitating round & fan flow pattern

AREAS OF APPLICATION

Electrical equipment - Pilot India
Electrical
Handicrafts - Pilot India
Handicraft
Automobiles - Pilot India
Automobiles
Furniture - Pilot India
Furniture
Sports - Pilot India
Sports
Type 64 S - Pilot India
TECHNICAL DATA
Code No. 64000S
Cup capacity (litres)- 0.34
Gun distance from work piece mm(inch) – 228.6(9)
Fluid nozzle orifice dia. (mm) 1.6
Required pressure (kgs/sq.cm) 2.1-2.8
Air consumption of rated pressure lit/min (c.f.m) 115 – 170 (4-6)
Material output (cc/min) 300
Max. pattern width (mm) 180
Min. Air-compressor (HP) 1
Weight of gun with cup (gms) 457

pdf 1 - Pilot India   Download product catalogue
pdf 1 - Pilot India   Download product manual

TYPE 68 N

(Spray Gun)


FEATURES
  • Iconic design & performance
  • Lightweight sleek ergonomic design for precision work
  • Symmetric & durable gravity cup
  • Built-in air control for finer adjustment
  • Permits exquisite shading & blending
  • Accurate & easy trigger control
      TECHNICAL DATA
      Code No. 68000
      Cup capacity (litres)- 0.14
      Gun distance from work piece mm(inch) – 228.6(9)
      Fluid nozzle orifice dia. (mm) 0.8
      Required pressure (kgs/sq.cm) 1-2.5
      Air consumption of rated pressure lit/min (c.f.m) 55-115(2-4)
      Material output (cc/min) 85
      Max. pattern width (mm) 100
      Min. Air-compressor (HP) 1
      Weight of gun with cup (gms) 304
      pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

      AREAS OF APPLICATION

      Artistry - Pilot IndiaArtistry Handicrafts - Pilot India
      Handicrafts
      - Pilot India
      Textile
      Laboratory - Pilot India
      Laboratory
      Sculpture 2 - Pilot India Pottery

      TYPE 68 S

      (Spray Gun)


      FEATURES
      • Iconic design & performance
      • Lightweight sleek ergonomic design for precision work
      • Symmetric & durable gravity cup
      • Built-in air control for finer adjustment
      • Permits exquisite shading & blending
      • Accurate & easy trigger control
          TECHNICAL DATA
          Code No. 68000
          Cup capacity (litres)- 0.14
          Gun distance from work piece mm(inch) – 228.6(9)
          Fluid nozzle orifice dia. (mm) 0.8
          Required pressure (kgs/sq.cm) 1-2.5
          Air consumption of rated pressure lit/min (c.f.m) 55-115(2-4)
          Material output (cc/min) 85
          Max. pattern width (mm) 100
          Min. Air-compressor (HP) 1
          Weight of gun with cup (gms) 366
          pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

          AREAS OF APPLICATION

          Artistry - Pilot IndiaArtistry Handicrafts - Pilot India
          Handicrafts
          - Pilot India
          Textile
          Laboratory - Pilot India
          Laboratory
          Sculpture 2 - Pilot India Pottery

          TYPE 68 N

          (Spray Gun)


          FEATURES
          • Iconic design & performance
          • Lightweight sleek ergonomic design for precision work
          • Symmetric & durable gravity cup
          • Built-in air control for finer adjustment
          • Permits exquisite shading & blending
          • Accurate & easy trigger control

              AREAS OF APPLICATION

              Artistry - Pilot India
              Artistry
              - Pilot India
              Textile
              Laboratory - Pilot India
              Laboratory
              Handicrafts - Pilot India
              Handicrafts
              Sculpture 2 - Pilot India
              Pottery
              Type 68 N - Pilot India
              TECHNICAL DATA
              Code No. 68000
              Cup capacity (litres)- 0.14
              Gun distance from work piece mm(inch) – 228.6(9)
              Fluid nozzle orifice dia. (mm) 1=0.8
              Required pressure (kgs/sq.cm) 1-2.5
              Air consumption of rated pressure lit/min (c.f.m) 55-115(2-4)
              Material output (cc/min) 85
              Max. pattern width (mm) 100
              Min. Air-compressor (HP) 1
              Weight of gun with cup (gms) 304

              pdf 1 - Pilot India   Download product catalogue
              pdf 1 - Pilot India   Download product manual

              TYPE 68 S

              (Spray Gun)


              FEATURES
                • Iconic design & performance
                • Lightweight sleek ergonomic design for precision work
                • Symmetric & durable gravity cup
                • Built-in air control for finer adjustment
                • Permits exquisite shading & blending
                • Accurate & easy trigger control

                    AREAS OF APPLICATION

                    Artistry - Pilot India
                    Artistry
                    - Pilot India
                    Textile
                    Laboratory - Pilot India
                    Laboratory
                    Handicrafts - Pilot India
                    Handicrafts
                    Sculpture 2 - Pilot India
                    Pottery
                    Type 68 S - Pilot India
                    TECHNICAL DATA
                    Code No. 68000
                    Cup capacity (litres)- 0.14
                    Gun distance from work piece mm(inch) – 228.6(9)
                    Fluid nozzle orifice dia. (mm) 1=0.8
                    Required pressure (kgs/sq.cm) 1-2.5
                    Air consumption of rated pressure lit/min (c.f.m) 55-115(2-4)
                    Material output (cc/min) 85
                    Max. pattern width (mm) 100
                    Min. Air-compressor (HP) 1
                    Weight of gun with cup (gms) 366

                    pdf 1 - Pilot India   Download product catalogue
                    pdf 1 - Pilot India   Download product manual

                    TYPE P-70 WITH CUP

                    (Spray Gun)


                    FEATURES
                    • Iconic design & performance
                    • Large surface area coverage
                    • Symmetric & durable suction feed cup
                    • Superior air cap performance
                    • Built-in spreader control for round & fan flow patterns
                    • Optimum for high speed production
                    • Compatibility with pressure feed tanks
                    TECHNICAL DATA
                    Code No. 70000
                    Cup capacity (litres)- 1
                    Gun distance from work piece mm(inch) – 228.6(9)
                    Fluid nozzle orifice dia. (mm) 1.7
                    Required pressure (kgs/sq.cm) 2.5-5
                    Air consumption of rated pressure lit/min (c.f.m) 200-283(7-10)
                    Material output (cc/min) 200
                    Max. pattern width (mm) 300
                    Min. Air-compressor (HP) 2
                    Weight of gun with cup (gms) 973
                    pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

                    AREAS OF APPLICATION

                    Industrial - Pilot India
                    Industries
                    Automobiles - Pilot India
                    Automobiles
                    Railways - Pilot India
                    Railways
                    Ship Building - Pilot India
                    Ship-Building

                    TYPE P-70 WITH CUP

                    (Spray Gun)


                    FEATURES
                    • Iconic design & performance
                    • Large surface area coverage
                    • Symmetric & durable suction feed cup
                    • Superior air cap performance
                    • Built-in spreader control for round & fan flow patterns
                    • Optimum for high speed production
                    • Compatibility with pressure feed tanks
                    AREAS OF APPLICATION
                    Industrial - Pilot India
                    Industries
                    Railways - Pilot India
                    Railways
                    Automobiles - Pilot India
                    Automobiles
                    Ship Building - Pilot India
                    Ship-Building
                    Type P 70 with cup - Pilot India
                    TECHNICAL DATA
                    Code No. 70000
                    Cup capacity (litres)- 1
                    Gun distance from work piece mm(inch) – 228.6(9)
                    Fluid nozzle orifice dia. (mm) 1.7
                    Required pressure (kgs/sq.cm) 2.5-5
                    Air consumption of rated pressure lit/min (c.f.m) 200-283(7-10)
                    Material output (cc/min) 200
                    Max. pattern width (mm) 300
                    Min. Air-compressor (HP) 2
                    Weight of gun with cup (gms) 973

                    pdf 1 - Pilot India   Download product catalogue
                    pdf 1 - Pilot India   Download product manual

                    TYPE P-70 WITHOUT CUP

                    (Spray Gun)


                    FEATURES
                    • Iconic design & performance
                    • Large surface area coverage
                    • Superior air cap performance
                    • Built-in spreader control for round & fan flow patterns
                    • Optimum for high speed production
                    • Compatibility with pressure feed tanks
                        TECHNICAL DATA
                        Code No. 70000 w/c
                        Cup capacity (litres)- 1
                        Gun distance from work piece mm(inch) – 228.6(9)
                        Fluid nozzle orifice dia. (mm) 1.7
                        Required pressure (kgs/sq.cm) 2.5-5
                        Air consumption of rated pressure lit/min (c.f.m) 200-283(7-10)
                        Material output (cc/min) 200
                        Max. pattern width (mm) 300
                        Min. Air-compressor (HP) 2
                        Weight of gun with cup (gms) 650
                        pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

                        AREAS OF APPLICATION

                        Industrial - Pilot India
                        Industries
                        Automobiles - Pilot India
                        Automobiles
                        Railways - Pilot India
                        Railways
                        Ship Building - Pilot India
                        Ship-Building

                        TYPE P-70 WITHOUT CUP

                        (Spray Gun)


                        FEATURES
                        • Iconic design & performance
                        • Large surface area coverage
                        • Superior air cap performance
                        • Built-in spreader control for round & fan flow patterns
                        • Optimum for high speed production
                        • Compatibility with pressure feed tanks



                              AREAS OF APPLICATION

                              Industrial - Pilot India
                              Industries
                              Railways - Pilot India
                              Railways
                              Automobiles - Pilot India
                              Automobiles
                              Ship Building - Pilot India
                              Ship-Building
                              Type P 70 - Pilot India
                              TECHNICAL DATA
                              Code No. 70000 w/c
                              Cup capacity (litres)- 1
                              Gun distance from work piece mm(inch) – 228.6(9)
                              Fluid nozzle orifice dia. (mm) 1.7
                              Required pressure (kgs/sq.cm) 2.5-5
                              Air consumption of rated pressure lit/min (c.f.m) 200-283(7-10)
                              Material output (cc/min) 200
                              Max. pattern width (mm) 300
                              Min. Air-compressor (HP) 2
                              Weight of gun with cup (gms) 650

                              pdf 1 - Pilot India   Download product catalogue
                              pdf 1 - Pilot India   Download product manual

                              TYPE P-80

                              (Spray Gun)


                              FEATURES
                              • Large surface area coverage
                              • Symmetric & durable gravity cup (large size)
                              • Superior air cap performance
                              • Built-in spreader control for round & fan flow patterns
                              • Optimum for high speed production
                              TECHNICAL DATA
                              Code No. 80000
                              Cup capacity (litres)- 0.75
                              Gun distance from work piece mm(inch) – 228.6(9)
                              Fluid nozzle orifice dia. (mm) 1.6
                              Required pressure (kgs/sq.cm) 2.5-5
                              Air consumption of rated pressure lit/min (c.f.m) 200-283 (7-10)
                              Material output (cc/min) 300
                              Max. pattern width (mm) 300
                              Min. Air-compressor (HP) 2
                              Weight of gun with cup (gms) 830
                              pdf 1 - Pilot India   Download product catalogue pdf 1 - Pilot India   Download product manual

                              AREAS OF APPLICATION

                              Industrial - Pilot India
                              Industries
                              Automobiles - Pilot India
                              Automobiles
                              Chemicals - Pilot India
                              Chemicals
                              Ship Building - Pilot India
                              Ship-Building

                              TYPE P-80

                              (Spray Gun)


                              FEATURES
                              • Large surface area coverage
                              • Symmetric & durable gravity cup (large size)
                              • Superior air cap performance
                              • Built-in spreader control for round & fan flow patterns
                              • Optimum for high speed production

                              AREAS OF APPLICATION

                              Industrial - Pilot India
                              Industries
                              Chemicals - Pilot India
                              Chemicals
                              Automobiles - Pilot India
                              Automobiles
                              Ship Building - Pilot India
                              Ship-Building
                              Type P 80 - Pilot India
                              TECHNICAL DATA
                              Code No. 80000
                              Cup capacity (litres)- 0.75
                              Gun distance from work piece mm(inch) – 228.6(9)
                              Fluid nozzle orifice dia. (mm) 1.6
                              Required pressure (kgs/sq.cm) 2.5-5
                              Air consumption of rated pressure lit/min (c.f.m) 200-283 (7-10)
                              Material output (cc/min) 300
                              Max. pattern width (mm) 300
                              Min. Air-compressor (HP) 2
                              Weight of gun with cup (gms) 830

                              pdf 1 - Pilot India   Download product catalogue
                              pdf 1 - Pilot India   Download product manual
